Tempest Bale Slicer

A groundbreaking solution developed in partnership between Chinook Hay Systems and Ghost River Systems Inc., designed to optimize your hay processing operations. The Tempest allows producers to capitalize on the efficiency of large square balers while delivering retail-ready, small bale products suitable for the feed store and equine industry.

Key Features

Efficiency & Scale: Leverages the speed of large square balers (up to 10x faster than small balers).
Retail-Ready Bales: Processes large 3x3 and 3x4 bales into consistent small bales (approx. 40-45 lbs).
Cost-Effective: Engineered for domestic needs, avoiding expensive hydraulic compression systems.
Reduced Labor Costs: Streamlines the process from field to customer.
Minimized Waste: Precise cutting mechanism reduces hay waste.
Optimal Density: Retains original field bale density, ideal for livestock feeding.

The Process

Large bales are loaded, twine is removed (manually or automatically), and bales are pushed through fixed cutting blades. Slices are separated and fed into a bale chamber for final sizing before optional output to a unitizing/bundling system.

Specifications

Input Bale Sizes: 3'x3'x8' and 3'x4'x8'
Output Bale Size: Approx. 20" x 17" x 16" (~40-42 lbs)
Transport Optimization: Approx. 1080 bales / 43,200 lbs per 53' dry van.
Unitizing Option: Available (36 bales per pallet).

Availability

The first unit is nearing completion (as of early 2025). Next delivery anticipated for November 2025.

Wraith Bale Former

The Wraith Bale Former processes loose-fed Alfalfa into large-sized, retail-ready sleeved bales, typically weighing between 330 - 370Kg (approx. 725 - 815 lbs).

Designed with a product-focused approach for robustness and adaptability, the Wraith emphasizes modularity to allow for various configurations and integration with existing customer facilities and handling equipment.

Key Features

Processes loose-fed Alfalfa.
Designed for robustness and adaptability (product-focused, not one-off).
Modular design for configurable layouts and integration.
Prioritizes hay quality preservation (minimal damage/loss, fines/dust reduction).
Focus on reliability and operator safety (guarding, interlocks, E-stop).
Intuitive controls (OMRON PLC, Exor HMI).
Adaptable to variations in input material.

Specifications

Input: Loose-fed Alfalfa (from customer system).
Output Bale Size: Approx. 42" x 44" x 32" (106cm x 112cm x 81cm).
Output Bale Weight: Approx. 330 - 370Kg (725 - 815 lbs).
Packaging: Designed for bagging sleeves.
Target Production Rate: 10 metric tons per hour (~30 bales/hr).
Hydraulics: Estimated 150-200 HP power pack required.
